V16 series power distribution box
Flush metal box with solid door and plastic lock, 12 to 36 ways, 100A.
Ask our sales team for the price.
A flush-mounted MCB power distribution box with a solid door and plastic lock. Door, frame and base box are 1.2 mm cold-rolled sheet, the breaker wiring box is red copper and the earth/neutral bars are brass. Rated 100A, 400V, IP30.
Specifications
- Family
- Distribution equipment
- Materials
- Metal
- Applications
- Homes and buildings
- Rated current
- 100A
- Rated voltage
- 400V~
- Protection
- IP30
- Material
- 1.2 mm cold-rolled sheet · breaker wiring box red copper · E/N bars brass
- V16MCB-12/A
- 12 ways · 410×482×118 mm
- V16MCB-18/A
- 18 ways · 410×552×118 mm
- V16MCB-24/PA
- 24 ways · 410×612×118 mm
- V16MCB-36/PA
- 36 ways · 410×712×118 mm
